QBiX Pro Series (3.5" Embedded Systems)
QF-N150A
- New
Key Features
Network appliance system with Intel® Processor N150/ Fanless design/ Single Channel DDR5 memory/ 6 x 2.5GbE LAN
• System Size : 172W x 105.8D x 44H(mm)
• Intel® Processor N150
• Single Channel DDR5, 1 x SO-DIMM
• DC input : 12V~36V Full Range
• Fanless design
• Onboard TPM v2.0
QBiX Pro Series (3.5" Embedded Systems)
QF-N150A
Specification
Dimension
172W x 105.8D x 44H(mm)
CPU
Intel® Processor N150
Intel 7, 4 cores, up to 3.60 GHz
Memory
1 x DDR5 SO-DIMM sockets, Max. Capacity 16 GB
Support Single channel DDR5 4800 MHz memory modules
Ethernet
6 x 2.5GbE LAN Ports (Realtek RTL8125D)
Graphics Support
Integrated Graphics Processor -Intel® Graphics supports:
1 x HDMI 2.0 port, supporting a maximum resolution of 4096x2160 @60Hz
Expansion-Slots
1 x 2280 M.2 M-Key (PCIe Gen3x2)
1 x 2230 M.2 E-Key
Front I/O
6 x RJ45 LAN Ports
1 x Console Port (RS-232)(RJ45 Type)
2 x External Antenna Holes (Optional)
Rear l/O
1 x GPIO (8 bits)
1 x Power button
1 x HDMI
2 x USB 3.2 Gen 2 (10 Gbps)
2 x USB 2.0
6 x LAN status LED
1 x DC Jack (Screw Type)
TPM
Onboard TPM 2.0 security chip
INFINEON SLB9670VQ2.0
Power
+12V~36VDC (19V/65W)
Operation Temperature
Operating temperature: 0°C to 50°C
Operating humidity: 40°C @ 20-95% (non-condensing)
Non-operating temperature: -40°C to 85°C
Non-operating humidity: 60°C @ 95% (non-condensing)
Use wide temperature range memory and storage
Vibration During Operation
Operation: IEC 60068-2-64, 3 Grms, random, 5 ~ 500 Hz, 1 hr / Per Axis, With SSD/M.2 2280
Non-operation: IEC 60068-2-6, 2 G, Sine, 10 ~ 500 Hz, 1 Oct/min, 1 hr / Per Axis
Shock During Operation
Operation: IEC 60068-2-27, 50 G, half sine, 11 ms duration, With SSD
OS Compatibility
Windows 11 IoT Enterprise, version 25H2, x64
Windows 11 Enterprise LTSC 2024
Windows 11 IoT Enterprise LTSC 2024, x64
Windows 11 IoT Enterprise, version 24H2 x64
Packing Content
Carton size: 590 x 321 x 238 (mm)
Packing Capacity: 5pcs
Single Box size: 301 x 198 x 112 (mm)
Single Box weight: Approx. 1.9kg
Including:
Power Cord : Optional (by region)
PSU ADP 19V 65W 100-240VAC x 1 (P/N: 25EP1-100651-A3S)
Mounting
Wall mount P/N: 25HB2-CGAA20-CHR x 1 (Optional)
VESA 75/100 P/N: 25HB1-TPL021-S8R x 1 + 12KSZ000001-00R x 1 (Screw) (Optional)
Order Information
6BQFN150AMR-SI (Box packing)
