2022-11-23
Press Releases
New Launch: DIN Rail System with Intel® Elkhart Lake Platforms
GIGAIPC, an embedded solution-focused subsidiary from GIGABYTE, is continuously to launch breakthrough and innovative products with Intel® Elkhart Lake processors for factory automation and smart retail industries.
QBiX-DR-EHLA6412H-A1 (for Industrial Field) is the latest embedded system product in QBiX DIN Rail Systems series, which remains the DIN Rail mounting design to let users install the industrial control equipment on the rail-rack vertically or horizontally based on their plant layout. The fanless design allows the device to perform noiseless at operating temperatures of 0°C to +50°C and is covered with rugged aluminum enclosure for better heat dissipation in order to keep high computing performance in severe working environment. Abundant IO ports and expansion slots, such as 4 x switchable COM ports, 2 x USB 3.2, 2 x USB 2.0, 1 x GPIO (8-bits), 1 x 2280 M.2 M-Key, 1 x 2230 M.2 E-Key, 1 x 3052/3042 M.2 B key with SIM Slot (5G support) satisfy all kinds of needs of industrial application.
QBiX-Plus-EHLA6412-A1 (for Retail Market) supports 3 independent display outputs via 3 x HMDI 2.0 ports, up to 4K resolution, which is perfect match for video walls, digital menu boards and billboards, which is not only easy for administrators to do quick signage installation, but also saving the operating expense by remotely updating or adjusting the digital contents or settings through ethernet. The fanless design with only less than 3mm thickness is also ideal for any field of space-limited environments, especially in the restaurant or retail stores. The essential IO ports of 4 x USB 3.2, 1 x COM and 2 x LAN ports are pretty enough for retail applications.
| Model | ||
|---|---|---|
| Order Information | 6BDR6412AMR-SI | 6BQS6412AMR-SI (CTO) |
| CPU | Intel® Celeron® J6412 Processor (Code Name: Elkhart Lake) | |
| Memory | 1 x DDR4 SO-DIMM, Max. Capacity 32 GB | 2 x DDR4 SO-DIMM, Max. Capacity 32 GB |
| Storage | 1 x 2.5” HDD/SSD (SATA 6Gb/s) | |
| LAN | 2 x GbE LAN Ports (Intel® I210AT) | 2 x GbE LAN Ports |
| Expansion Slots |
1 x 2280 M.2 M-Key (SATA 6Gb/s, support NVMe SSD) 1 x Full-size mini PCIe w/ SIM slot |
1 x 2280 M.2 M-Key (PCIe x4, SATA 6Gb/s) 1 x 2230 M.2 E-Key (WiFi/BT) |
| Front I/O | 2 x RJ45 LAN Ports 2 x USB 3.2 Gen 1 2 x USB 2.0 + 1 x Vertical USB inside 1 x HDMI 1 x VGA 2 x COM Ports (RS-232/422/485 & RI/5V/12V) 1 x Power switch 1 x HDD & Wi-Fi LED 1 x Remote control pin 1 x Headphone Jack 1 x External Antenna Hole (Optional) |
2 x USB 3.2 Gen 1 (1 port – share 3052 and Rear IO) 1 x COM Port (RS-232) 1 x Micro SD card slot (USB2.0) 1 x Power button with LED 1 x HDMI |
| Rear I/O | 1 x Din Rail Mounting Support |
1 x Combo Audio Jack (Microphone & Headphone) 1 x DC Jack |
| Side I/O | 1 x GPIO (8 bits) 1 x 3-pin Terminal Block 2 x COM Ports (RS-232/422/485) 2 x External Antenna Holes (Optional) |
3 x External Antenna Holes (Optional) |
| Power Supply | +9V~36VDC (Full Range) | +12~19VDC (Adapter 19V/65W) |
