PICO-G700
- Preliminary
Key Features
PICO-ITX with Arm® Cortex®-A78, Onboard LPDDR4 8GB, eMMC 64GB, 2 x USB 3.0, 1 x USB Type-C OTG
- PICO-ITX form factor
- MT8390 Arm® Cortex®-A78
- 4 Channels LPDDR4 8GB (on board)
- eMMC 64GB
- HDMI, MIPI, eDP for dual Display support
- Wide voltage support 12~24V
- Wide Temperature support
Pico-ITX
PICO-G700
Specification
Form Factor
PICO ITX
100W x 72D (mm)
CPU
MT8390
2x A78 2.2GHz L2 256KB, 6xA55 2.0GHz L2 128KB, shared 2MB L3 cache
Memory
4 Channels LPDDR4 8GB (on board)
Ethernet
PHY, RTL8211FI-CG (10/100/1000 Mbps)
Video
HDMI 2.0
eDP (2 x Lan)
MIPI-DSI (DSI 7” 1920*1200) (Optional)
Audio
MT6365 (Integrated)
Storage
eMMC v5.1 64GB (on board)
Expansion Slots
2230 M.2 E-key slot (PCIe x1, USB2.0)
WIFI6 : AW-XB468NF(IC:MT7921L)
3042/3052 M.2 B-Key(USB3.0)
5G : RM500K-CN / RM520N-GL
Internal I/O
1 x Front panel header
1 x Speaker header (2W/4ohm)
2 x UART
1 x GPIO (8 bits) header
1 x MIPI-DSI (optional)
2 x I2C (Touch & BLK)
1 x DC in (box header)
1 x power button
Rear l/O
1 x DC In power jack - System adapter 12~24V
2 x USB 3.0 Ports (Host)
1 x USB Type C (OTG)
1 x RJ45 LAN Port
1 x Micro SD slot
1 x HDMI
1 x Audio Jack
Operating Properties
Operating temperature: -20°C to 60°C
Order Information
9MG700UJMR-SI (Box packing)
∗ All specifications are subject to change without notice. Please contact with your sales representative for more information.
